MCJ Optics HUYM76 - 8x28 Compact Monocular – Waterproof, Nitrogen-Filled, BMC Coated

MCJ Optics HUYM76 - 8x28 Compact Monocular – Waterproof, Nitrogen-Filled, BMC Coated

Shipping calculated at checkout.
Lifetime Warranty

MCJ Optics 8x28 Compact Monocular is the go-anywhere optic built for hunters, hikers, and outdoor enthusiasts who demand performance in a pocket-sized package. With bright optics, rugged waterproof construction, and nitrogen-purged internals, it’s ideal for fast field scanning and quick close-to-mid-range spotting.

The 28mm objective lens and BMC multi-coated glass deliver sharp, high-contrast images. Despite its compact 150g build, this monocular features a robust waterproof structure and is all-weather ready, performing even under spray or shallow submersion (1m for 30 minutes).

Twilight index of 14.4 and 12mm eye relief make this model practical in low-light conditions and comfortable for extended use — all in a palm-sized unit that fits your pocket or gear bag.

Key Features:

  • 8x magnification with wide 6.8° field of view
  • 28mm objective lens with BMC multi-coated optics
  • Waterproof construction rated for 1m submersion / 30 minutes
  • Nitrogen-filled for fog resistance and long-term clarity
  • Compact and ultralight – only 150g
  • Minimum focusing distance of 1.6 meters (4.8 ft)
  • All-weather performance with ±3 parallax adjustment

Technical Specifications:

Model MOF-MO-HUYM76
Magnification 8x
Objective Lens Diameter 28mm
Prism Type BK-7
Lens Coating BMC (Broadband Multi-Coated)
Prism Coating No
Number of Lens Groups 6 pieces / 4 groups
Exit Pupil Diameter 3.0mm
Eye Relief 12mm
Field of View 6.8° / 357 ft @ 1000 yd / 119 m @ 1000 m
Minimum Focus Distance 1.6m / 4.8 ft
Relative Brightness 9
Twilight Index 14.4
Resolution 8"
Parallax Adjustment ±3
Waterproof Rating 1m for 30 minutes
Nitrogen Filled Yes
All-Weather Use Yes
Product Dimensions 118 × 37 × 37 mm
Product Weight 150g

Ultra-portable yet tough enough for the wild — backed by MCJ’s lifetime warranty and field-tested reliability.
